Door Skirt Extrusion PVC Plastic Profile Production Line Double Screw Design
Contact Person : Coco
Phone Number : +8618013292369
WhatsApp : +8618013292369
| Minimum Order Quantity : | 1 SET | Price : | negotiation |
|---|---|---|---|
| Packaging Details : | Standard wooden package. | Delivery Time : | 30 days after payment |
| Supply Ability : | 20 sets per month |
| Place of Origin: | JIANGSU | Brand Name: | FRIEND |
|---|---|---|---|
| Certification: | CE | Model Number: | SJSZ-80/156 |
|
Detail Information |
|||
| Application: | PVC Panel Board | Raw Material: | PVC Powder |
|---|---|---|---|
| Voltage: | 220V,380V,or Customized | Motor Power: | 55 Kw |
| Brand Name: | Friend | Motor Brand: | SIEMENS BEIDE |
| Screw Design: | Double-screw | Transducer: | Rexroth |
| High Light: | 700mm pvc panel machine,Customized pvc panel machine,Customized pvc profile machine |
||
Product Description
Customized 700mm PVC Panel Board Plastic Profile Production Line
Details
WPC wood plastic composite profile extruder produced by our company adopts domestic and foreign composite technology, which has the characteristics of high degree of automation, stable performance, large output and high efficiency. The company is an enterprise specializing in the production of various outdoor and indoor WPC profiles, which can replace different molds---
Outdoor applications: WPC hollow panel, WPC solid panel, WPC beam / joist / keel, WPC wall cladding, WPC workbench / chair, WPC fence / railing, column / column, WPC Pavilion, WPC roof profile, etc
Indoor application: door and window profiles, furniture decoration profiles, foam profiles, etc
Features
1) The screw and cylinder of Zhoushan extruder adopt vacuum degassing system, which can discharge the raw material waste gas and ensure the final particle quality.
2) Gearbox: from jiangyin gearbox company, a famous brand in China, with beautiful appearance, stable operation, low noise and long service life.
3) Heating system: stainless steel plate cover cast aluminum heater and fan cooling system are adopted to ensure good cooling and heating performance and accurate temperature control.
4) Drive system: Siemens motor and ABB frequency converter are adopted, with stable torque output and various speeds.
5) Vacuum calibration cooling workbench: the workbench is made of #304 stainless steel with good strength and long service life.
6) Traction machine: rubber block traction belt, and the traction speed is adjusted by ABB frequency converter.
7) Cutting machine: saw blade cutting, low noise, fast cutting speed, with dust suction device.
Flow Chart
pvc powder+wood powder+additives → mixing → extrusion line ( conical twin-screw extruder → profile extrusion die → profile moulds→ vacuum calibration platform →haul-off → cutter →stacker → finished product) → surface finish processing ( like heat transfer,sanding, embossing,etc)
Main Technical Parameter
| Model | SJSZ-51/105 | SJSZ-65/132 | SJSZ-80/156 |
| Max production width(mm) | 200 | 250 | 600 |
| Extruder capacity(kg/h) | 100-120 | 150-180 | 250-380 |
| Main motor power(kw) | 22 | 37 | 75 |
| Vacuum pump power(kw) | 3 | 7.5*5.5 | 11*7.5 |
| Calibrating table length(mm) | 4000 | 6000 | 6000 |
