Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter

China Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter supplier
Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter supplier Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter supplier Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter supplier Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter supplier

Large Image :  Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter

Product Details:

Place of Origin: Jiangsu province,China
Brand Name: Friend
Certification: CE,SGS,TUV
Model Number: SJSZ65/132 double screw pipe machine

Payment & Shipping Terms:

Minimum Order Quantity: one set
Price: negotiation
Packaging Details: Film package or wooden package
Delivery Time: 30 worker days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Contact Now
Detailed Product Description
Material: PVC Powder Pipe Diameter: 16-63mm
Main Motor Power: 37kw After-sales Service Provided: Engineers Available To Service Machinery Overseas
Max Speed: 26meters/min Control: PLC+Touch Screen
Screen Brand: Simens S7 Contactor: Siemens Contactor
Inverter: ABB Brand Tempurature Control: Omron
Motor Brand: Simens Brand

Plastic 16-63mm PVC double pipe machine / extrusion line / production line



Features:



1. The host is a SJSZ51/105or SJSZ65/132 conical twinscrew extruder with a double pipe but single control stainless steel spraying forming machine which can assist avoiding a series of troubles caused by adjustment of any one tube.


2. This automatic singlecontrol double hauling machine and cutting machine are fully integrated with the double sizing techniques, which make the operation more flexible and bring more benefits of this single-control, double-pipe technique to you.


3. Radius of these double-pipe extruder ranges betweenφ16-φ63, so even for a small-radius pipe production, it can also achieve a high output.



Machine List:



Item Machine Quantity
1 SRL-Z Series Mixer one set
2 SJSZ65/132 or SJSZ51/105 series twin screw extruder one set
3 Mould and die one set
4 Vacuum calibration device one set
5 Haul off machine one set
6 Knife cutter machine one set
7 Stacker one set



Technical Parameters:



Model number PVC-16/63 PVC-20/110 PVC-50/160 PVC-75/250 PVC-110/315
Pipe diameter 16-63mm 20-110mm 50-160mm 75-250mm 110-315mm
Max output 120kg/h 120kg/h 180kg/h 300kg/h 450kg/h
Production rate 1.5-15m/min 0.8-8m/min 0.5-5m/min 0.4-4m/min 0.3-2m/min
Extruder model SJZ-51/105 SJZ-51/105 SJZ-55/110 SJZ-65/132 SJZ-80/156
Installed power 45kw 45kw 55kw 75kw 105kw
Center height 1000mm 1000mm 1000mm 1000mm 1100mm
Installation area 22*2.5*2.0m 24*2.8*2.0m 24*2.8*2.0m 30*2.8*2.2m

35*3.0*2.4 m





Picture:



SRL-Z Series Mixer:For mixing pvc powder

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter



SJSZ65/132 twin screw extruder:For extrudring

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter



Mould and die

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter



Vacuum calibration device:for forming and cooling the pipe

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter



Haul off machine: for tractor the pipe

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter



Knife cutting machine: for cut the pipe

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter



Stacker:for store the pipe

Simens Motor Brand Plastic Pipe Manufacturing Machine 16-63mm Pipe Diameter
