| Brand Name: | Friend |
| Model Number: | SJ120 PP PE water ring recycling line |
| MOQ: | one set |
| Price: | negotiation |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 30 sets per month |
Water Cooling Strand Plastic Pelletizer Machinery Granulator Plastic Machine
Strand pelletizing is a widely applied pelletizing process, suitable for almost all materials. This process features simple equipment structure and convenient operation and maintenance.
Craftwork
For strand pelletizing process, usually water bath, air knife, pelletizer and vibration sieve are provided. The system is in module design. So the user can add a hot air drying chamber, pneumatic conveying system, silo or other equipment to it as options according to process requirements.
The product is suitable for water cooling strand pelletizing line of all kinds of thermoplastic general engineering plastics and modified engineering plastics, such as ABS,PA,PC,PE,PET,POM,PP,PPS,PS,etc., including glass fiber reinforced and inorganic filled thermoplastic extrusion.
| Model | SJ-100 | SJ-120 | SJ-160 | |
| Belt Conveyor | Motor power | 1.5kw | 1.5kw | 2.2kw |
| Comprossor | Motor power | 55kw | 75kw | 90kw |
| Output | 180-220kg/h | 250-330kg/h | 500-600kg/h | |
| Extruder | L/D | 28:1 | 30:1 | 30:1 |
| Motor power | 90kw | 110kw | 135kw | |
| Material | 38CrMoALA | |||
| Output | 180-220kg/h | 250-300kg/h | 500-600kg/h | |
| Dewatering machine | Motor power | 3kw | 4kw | 5.5kw |
| Fan power | 3kw | |||
Equipment
......................................................................................................................................................................
PP and PE water-ring cutting pelletizer machine
PP and PE water-ring cutting pelletizer machine
PP and PE water-ring cutting pelletizer machine
PP and PE water-ring cutting pelletizer machine
PP and PE water-ring cutting pelletizer machine
