Pe Ps Waste Plastic Making Pe Pelletizing Machine Granulation Production Line
Contact Person : Coco
Phone Number : +8618013292369
WhatsApp : +8618013292369
|Minimum Order Quantity :||1 set||Price :||negotiation|
|Packaging Details :||film packing and wooden case||Delivery Time :||30 making days|
|Supply Ability :||20 sets per year|
|Place of Origin:||Jiangsu,China||Brand Name:||Friend|
|Material:||Recycle Plastic Scrap||Extruder:||Single Screw Extruder|
|Screw:||Vented Screw||Gearbox:||GUOMAO Brand|
|Control System:||Siemens , Omron, ABB||Warranty:||1 Year|
HDPE Plastic Pelletizer Machine,
LDPE Plastic Pelletizer Machine,
LDPE plastic pelletizing line
Ldpe Hdpe Plastic Pellet Extruder Pelletizer Pelletizing Machine
We’re very professional manufacturer of plastic recycling machinery, and We have been working in this industry for over than 15 years, We have developed many different kinds of plastic granulators for different material, such like PP PE PVC PET PC ABS EPE EPS, Printed and non-printed PE, PP film, multi-layered film, shrink film, stretch film, PE and EPE foam, Thermoformed PS, PP, Soft irrigation pipe, Pre-shredded regrind, Washed and dried film flakes from washing line,Hard Plastic Regrind, Washed Material, Granules, HDPE-milk-bottles etc. And adopt different feeding ways for rigid flakes and for soft fluffy scraps. Output capacity will be from 100KG/H up to 1000kg/H.
1. High strength and elastic coefficient, high impact strength and wide temperature range;
2. High transparency and free dyeing;
3. Low shrinkage and good size stability;
4. Poor fatigue resistance;
5. Good weather resistance;
6. Excellent electrical characteristics;
7. Odorless and odorless are harmless to human health.
8. Machine design lower consumption and noise , easy and safe operation .
9. ABB, RKC,OMRON,SIEMENS brand
10. 1year warranty time
Machine detailes :
2. SJ65 Single Screw Extruder
|Screw diameter :65mm|
|Screw and Barrel making material: 38CrMoAlA|
|Hardness of Screw : HV900-1000|
|Depth of Nitrogen Treatment: 0.4-0.7 mm|
|Screw Straightness: ＜0.015 mm|
|Main Motor Power :30kw|
|Barrel heater type : Cast aluminum heater+304 stainless steel cover|
|Heating temperature range: 0-320℃|
|Heating power: barrel + mold|
|Barrel cooling type: forced air cooling|
|Screw type : vent screw|
|Fan power: 1.5kw|
|Screw Max Rotating Speed: :13-130rmp|
|Center height: 1000mm|
|Control system :|
|ABB brand frequency converter (speed control)|
|Omron brand temperature meter( temperature control )|
|Siemens brand contactor|
|AoYi brand ampere meter|
|Screw and Barrel brand: zhoushan brand|
Gearbox brand : jiangyin brand ,
Gear type: hard tooth -faced speed reducer
|Motor brand: xindali brand ( CE marked )|
|3. Hydraulic net changer||Hydraulic station, motor power 1.5 KW, accumulator, 10 l filter before the installation of pressure sensor, skateboard reversing cylinder controlled by manual reversing valve, oil system of maximum working pressure of 16 mpa, oil hydraulic system can automatically supply, and a constant to the set value. 0|
|Net changer: double net changer, 38 crmoal nitriding material handling, HV950-105|
|4. Mold||Mold and head material : 40Cr steel|
|High quality tooling steel|
|Mold hardness: HV950-1050|
|Final pet strand hole size : 3mm diameter or Could be customized|
|Heating band and thermocouple matched : yes|
5. Water Cooling Tank
|Working performance: final pet strand cooling|
|Main making material : 304 stainless steel|
|Tank length: 4M|
|Machine structure: Q235 steel|
|Matched with nylon material traction rollers *4pcs|
|Including water valves|
|Center height 1000mm|
|Tank height adjustment : +-90mm|
6. Blower Dryer and Pelletizer
|Heating dryer driving motor: 2.2kw|
|Drying pipe making material: 304 stainless steel|
|Traction roller making material: 4pcs*nylon material|
|Water collection device for reuse: yes|
|Granule cutting machine power: 3kw|
|Motor brand: china brand with CE|
|Cutting Speed : variable|
|Traction type: rubber roller traction|
|Traction roller clamp type : manual screw press|
|Cutting blade making material: 9Crsi steel material|
|Blade； 1 pcs fixed blade ,1 pcs rotating blade|
|Cutting speed control : ABB frequency converter|
|Center height: 1000mm|
7. Vibrating Screen
|Driving motor power: 0.55kw*2|
|Vibrating motor brand； China brand with CE|
|Adopt two layers screen|
|Screen size could be designed.|
|All parts touched with granule is made by high quality 304stainless steel|
Why choose us?
We are a professional manufacturer of Plastic Extruders ,we produce plastic extrusion machine.
1. Cost performance is high
All the machine ,we make it ourself to reduce the cost of our customer.
2. Genuine product with excellent quality
We choose our material andequipment strictly.
All the material come to our factory must pass the quality test.
3. Engerneers available to serve oversea
4. Quick delivery
The company provide just in time delivery with its streamlined supply chain.
5. Cost saving
We take strong attention to every detail in the manufacturing process.
The quality control in our factory is very strict.
All defective semi-manufactures must be treated again or reject.
All the machine must be checked out ,then delivered to our customer.
All about that pushing up the price,but get good quality machine.
What we want to do is give our customer a good quality product with stable working and long lived.
Q: What is your delivery time?
A: Normally, it needs about 30 days. The exact time depends on production management.
Q: How long is your delivery time?
A: Generally it is 10-20 days if the goods are in stock. or it is 35-60 days if the goods are not in stock, it is according to quantity.
> Introducing in detail features and application of the products to customer
> Selecting economical and practical machine & equipment for customer
> Providing operation data of the related machine & equipment
> Providing means of trial performance for customer
> Recommending engineering conditions required for installation of the machine & equipment
> Communicating in time the manufacturing progress of the machine with user
> Providing assistance in technical conditions, screw combination and barrel disposition needed for product
> Providing on-the-spot technical assistance in installation, commission and training
> Filling in detail customer’s information
> Providing long-term maintenance service and spare parts
> Giving technical support to customer for developing new product
> Providing free maintenance for a year
