1.75mm 3mm 3d Printer Filament Making Machine Automatic Control 20kg Output

Brand Name:	FRIEND
Model Number:	SJ45
MOQ:	one set
Price:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	30 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu province,China

Certification:

CE,SGS,TUV

Material:

PLA,ABS,PEEK,etc.

Length:

13meters

HS Code:

84778000

Capacity:

15-25kg/h

Control:

Automatic

Install Power:

About 50kw

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Delivery Time:

20 Days

Packaging Details:

wooden package

Supply Ability:

30 sets per month

Highlight:

3d printer filament maker

3d printer filament extruder machine

Product Description

1.75mm 3mm ABS PLA 3D printer filament extruder machine with 20kg output

1.75mm 3mm ABS PLA 3D printer filament extruder machine with 20kg output Processing Flow Chat:

Dryer hopper→single screw extruder→die head →hot water tank→cold water tank--tractor→storage machine→laser machine →winder

Product Features:

1. Use for ABS, PLA material with good plasticizing, and without crystal particle and bubble.
2. The product is provided with high precision, good roundness and linear dimension stability
3. The line has high capacity and can greatly improve the production efficiency.

NO.	Item name	Quantity
1	ABS/PLA single screw extruder	1 set
2	High precision extrusion mold	1 set
3	4m Warm water tank & 4m Water cooling tank	2 sets
4	Haul-off machine	1 set
5	Online laser gauge	1 set
6	8M Accumulator Machine	1 set
7	Dual-Shaft Winding Machine	1 set
8	Voltage:380V 50HZ or customized

Application:

1.75mm 3mm ABS PLA 3D printer filament extruder machine as its name is mainly used for extruding ABS/PLA filament.This machine can also process all kinds of plastic materials such as soft/hard propene Polymer (PP) and polystyrene(PE) coordinated with the appropriate auxiliary machine. Our factory can process the whole line to produce accurate ABS/PLA filament which includes: Feeder, extruder, mould, water tank, laser measuring machine, haul off machine and winding machine. Its max capability can reach 15kg/h.

1. Delivery date & payment terms

The machine will be ready in 25-30 days receiving deposit. We normally accept payment terms like 30% in advance as deposit, 70% T/T before delivery.

2. Installation and test running

We will invite customers to check the machine before shipment. And if the customer requests us to guide installment and test running in his factory, we will send our engineer. And the customer should pay for engineer’s ticket, visa, room and board, $80 per day for one people as allowance.

3. Quality guarantee

We normally guarantee machine quality for one year to key components of the machines, if key components of machine are broken for technical reason, we will replace it with new one free. (The customer should return broken components).

High precision 3D printer filament

1.75mm 3mm 3d Printer Filament Making Machine Automatic Control 20kg Output 0

Winding machine, automatic cut the filament

1.75mm 3mm 3d Printer Filament Making Machine Automatic Control 20kg Output 1
