Double Stage Waste Plastic Recycling Pelletizing Machine Non Pollution

Minimum Order Quantity : one set Price : negotiation
Packaging Details : Film package Delivery Time : 30-40 days
Payment Terms : L/C, D/A, D/P, T/T Supply Ability : 20 sets per month
Place of Origin: China Brand Name: Friend
Certification: CE Model Number: SJ

Detail Information

Material: PVC Cable Material Warranty: One Year
Application: Granule Screw Design: Double Screw
Control: Automatic After-sales Service Provided: Engineers Available To Service Machinery Overseas
Voltage: 380V Or Customized Power: Customized
High Light:

waste plastic recycling pelletizing machine

,

pvc granules making machine

Product Description

Double stage pellets recycled pvc granules plastic pelletizing machine



Description of plastic pelletizing machine:



1. plastic granulate machine is the successor to plastic master-sub granulator.



2. plastic granulate machine is installed by "one line" shape, "right and left" shape and "T" shape, which is saving the work space.



3.This machine is different from waste plastic machine, such as PP, PE, HDPE. especially resolved the problem of high-density polyethylene granulation broken bars.



4. plastic granulate machine is matched with plastic crusher and granular cutting machine. While the waste plastic materials through crushing and washing, could be put into extruder without drying. But the die head of machine could be electric screen changer or hydraulic screen changer.



5. Simple process, advanced technology, automatic temperature control, national energy-saving patented heater, low power consumption, non-pollution, high degree of automation.



Process Flow of plastic pelletizing machine:



HDPE bottle →convey feeding→magnetic screening →forced feeding→degassing single screw extruder→hydraulic screen exchanger→material outing mould→degassing single screw extruder →hydraulic screen exchanger → material outing mould →water tank→drying system →cutting granulating unit →storage hopper



Technical parameters of plastic pelletizing machine:

model 100-120 120-135 150-160 180-200
The first extruder
L/D 25-34 25-34 25-34 25-34
Power of main motor 55-75 75-110 90-132 110-185
Power of heating 40 45 55 70
Rotational speed 0-120 0-120 0-110 0-110
The second extruder
L/D 10-15 10-15 10-15 8-15
Power of second motor 22-30 30-37 30-45 45-55
Power of heating 25 30 35 45
Rotation speed 0-120 0-120 0-110 0-450
output 150-200 200-250 300-350

350-450








Double Stage Waste Plastic Recycling Pelletizing Machine Non Pollution 0
