PVC WPC PE Pelletizing Machine Plastic , PVC Granules Making Machine

Brand Name:	Friend
Model Number:	SJ
MOQ:	one set
Price:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	20 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Material:

PVC Cable Material

Warranty:

One Year

Application:

Granule

Screw Design:

Double Screw

Control:

Automatic

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Voltage:

380V Or Customized

Power:

Customized

Packaging Details:

Film package

Supply Ability:

20 sets per month

Highlight:

pvc granulating machine

pvc granules making machine

Product Description

PVC PE WPC pellet granulating production line / pvc pelletizing line

Description of PVC WPC pellet granulating line:

This pelletizing machine is composed of a conical twin-screw extruder and the corresponding pelletizing downstream equipment, it is suitable for the pelletizing of PVC, PE raw materials with wood powder or other additives. The pellets produced by this machine is evenly, solid, elegant. The pelletizing downstream equipment is the die face cutter, air transferring unit, vibration separating and cooling unit. This pelletizing downstream equipment has the feature of high automatic and high production efficiency.

Feature:

1. Conical double-screw extruder, very suitable to process PVC powder with high capacity

2. Granulating style: hot-cutting on mould face, even cutting ensures good shape.

3. Auxiliary machine: granulates cooling & classifying

A: This plastic pelletizing machine is mainly used for processing PVC compound material into pellets

B: production capacity can upto 350-400kg/h

C: quality certificate: CE and ISO9001-2000 quality certificate

D: Machine configuration:

1) single screw extruder or twin screw extruder

2) hot-cutting system

3) air-blowing system

4) pellets storage silo

Product Introduction:

SRJ series plastic wind-cooling ,hot-cutting pelletizer is used in the granulating of PVC resin, recycled plastic, thermoplastic, coloration materials, and filling material, etc.
This set consists of extruder, heating system, die, granule-cutting system, cooling discharging system and electricity controlling system.

Main Technical Data:

Model	SRJ65	SRJ80	SRJ90	SFJ120
L/D of screw	20:1	20:1	20:1	20:1
Main motor power(kw)	7.5	15	18.5	30
Heating power(kw)	6.5	9.5	11.5	15
Output(kg/h)	15-30	20-45	40-60	60-80
Blower fan(kw)	1.1	1.5	2.2	3
Granule-cutting power(kw)	0.75	0.75	1.1	1.5

Picture:

PVC WPC PE Pelletizing Machine Plastic , PVC Granules Making Machine 0
