Lab Mini 3D Printer Filament Extruder Machine / Production Line Low Noise
Contact Person : Coco
Phone Number : +8618013292369
WhatsApp : +8618013292369
| Minimum Order Quantity : | 1 set | Price : | USD 9000-29000 per set |
|---|---|---|---|
| Packaging Details : | standard wooden case | Delivery Time : | 35 working days |
| Payment Terms : | L/C, T/T, Western Union | Supply Ability : | 20 sets per month |
| Place of Origin: | China, Jiangsu | Brand Name: | Friend Machinery |
|---|---|---|---|
| Certification: | CE ISO SGS | Model Number: | FLD-25, FLD-35A, FLD-35B, FLD-45 |
|
Detail Information |
|||
| Voltage: | Can Be Customized | Condition: | New |
|---|---|---|---|
| Application: | Filament | Plastic Processed: | ABS,PP,PLA,PE,ABS/PLA |
| Screw Design: | Single-screw | Type: | 3D Printer Filament Extruder/ Extruding Machine |
| High Light: | Single screw 3d filament making machine,0.75KW 3d printer filament extruder machine,pla 3d printer filament extruder machine |
||
Product Description
This machine is mainly used for the processing of PLA, ABS, PEI, PETG, PEEK and other plastics. With various auxiliary machines, it can directly produce printing filament plastic products. It has the characteristics of simple production process, high output, stable quality and low cost.
The company has been engaged in the production of plastic extrusion equipment for 10 years, has rich experience and technical support, and its customers cover most of Europe and America.
Our company is the earliest manufacturer of 3D printing filament production line in China. It has been researching and selling equipment for 9 years. The products and equipment are spread all over the country and abroad, and we cooperate with many well-known domestic companies. We have a wealth of equipment experience, and we have different production processes and mature processes for the characteristics of raw materials. So far, our printing filaments can achieve an accuracy of ±0.02mm, and the winding is almost neat.
The company provides a complete set of equipment. In addition to the production line, we can also support vacuum packaging machines, color mixing machines, dehumidifying dryers and other auxiliary machines to provide customers with a complete set of solutions.
Zhangjiagang Friend Machinery Co., Ltd. has been committed to the production process of 3D printing consumables, and has provided stable 3D printing consumable production lines to most countries in the world.
In order to meet the printing needs of the majority of scientific research institutions, universities, and high-tech enterprises for special engineering materials, Zhangjiagang Friend Machinery Co., Ltd has developed a high-temperature material 3D printing consumable production process for PEEK. This production line uses a specific screw and cooling method. After repeated tests, it’s an ideal 3D printing consumable extrusion machine with stable production and easy operation.
|
Model |
extruder |
Drive power |
Output |
Control |
Application |
|
FLD-25 |
SJ-25 |
0.75KW |
0.5-2kg/h |
Control panel PLC touch screen(Optional) |
PLA/ABS/PETG
Other material can be customized |
|
FLD-35B |
SJ-35 |
5.5KW |
3-5kg/h |
Control panel PLC touch screen(Optional) |
|
|
FLD-35A |
SJ-35 |
7.5KW |
10-15kg/h |
PLC touch screen |
|
|
FLD-45 |
SJ-45 |
15KW |
15-25kg/h |
PLC touch screen |
1. Cooling: two-stage cooling, to solve the problem of deformation of the core.
2. Frame structure: the important part is welded with 6.0 thick steel plate or reinforced steel to consolidate the stability of the machine
3. Take-off wheel: dynamic balance processing to improve operation stability
4. Wire storage rack: 9 meters in length and 100 meters in storage length, which solves the difficulty of traditional wire collection
5. Control: The extruder can be set to match the measuring and control instrument, and the wire diameter can be automatically adjusted, which is more intelligent and convenient(PID control)
6. Meter counter: independent part, for meter counting and anti-return line function.
|
Main Motor |
SIEMENS BEIDE |
|
Transducer |
ABB |
|
Temperature controller |
OMRON |
|
Contractor |
SIEMENS |
|
Breaker |
SCHNEIDER |
|
Servo motor |
TECO |
|
PLC |
TECO |
1. We not only provide machines but also offer technical support and market evaluate.
2. We will provide all the machines for the complete production line according to customer's requirements.
3. We will provide complete service for factory layout and other information to help customer to build the factory.
4. We will provide good service for machine installation and training, until the customers can run the machines and make stably production.
5. Except for the one year warranty, we will provide after-sales service for all the time.
6. For long-term cooperation, we always provide good quality, good price and offer good service to customers.
