Wasted Plastic Tire Shredder And Crusher Machine For Plastic Recycled
Contact Person : Coco
Phone Number : +8618013292369
WhatsAPP : +8618013292369
Detail Information |
|||
Motor Power: | 15~55 Kw | Keywords: | Shredder For Plastics |
---|---|---|---|
Certification: | Approved | Motor Brand: | Siemens Beide |
Machinery Test Report: | Provided | Wall Thickness: | 10 Mm |
Warranty: | 1year | Place Of Origon: | Jiangsu,China |
Highlight: | 10mm WT plastic shredder granulator,removable blades plastic shredder granulator,10mm WT plastic Recycled granulator |
Product Description
Plastic Granulator Shredder PP PE PVC Plastic Crusher Machine Waste Plastic Recycled
Application
restore all kinds of plastic, particularly for various hard plastic, e.g. Blow molded products and shoes plastic.
1. Easy to operate, low electricity consumption & durable and Low nosie.
2.Uses Japan's high quality steel material especially for making cutter of the crushers,.
3.The blades can be grinded for many times and can be used repeatedly ,
4.Easy to clean and maintain; The hopper, crusher room, blades and screen can be removed and mounted easily.
5.Brand Motor and SCHNEIDER ELECTRIC with Over-loading protection
6.To crush all kinds of soft and hard plastic. High reliability,High efficiency and other plastic recycling industry.
Advantages
1.Adopting deafener, low in noise;
2.Adopting removable blades which can be separately replace or sharpened after getting blunt;
3.Adopting all copper motor , more lifetime for the machine.
3.Suitable for crushing all kinds of soft,hard and formed plastics.
4. Able to crush PET Bottle, easy to operate and small size.
Suitable Material
1. PET bottle, drink bottle label, bottle cap
2. PE film, agricultural film, bag, PE pipe, water pipe, drainage pipe
3. PP woven bag, PP water drum, PP cup, PP film, sheet, pallet, basket
4. LDPE/HDPE film, sheet, flake, lump, board
5. PVC pipe, profile, window frame, door frame, soft PVC door curtain
6. Wood plastic window/door
7. PC/ABS water drum
8. Rubber tyre, rubber/plastic material from injection mold
9. TV shell, keyboard, mouse, TV remote controller, toys, torch, plastic helmet, file folder, brochure
shelf, canvas, coat hanger, bumper bar, gas tank
10. Fiber, coconut fiber, jute fiber
11. Nylon
12. Non-woven fabric
13. Leather, artificial leather, leather shoes, leather clothes, leather hand bags
Main Technical Parameters
Model | JY-251 | JY-301 | JY-380 | JY-500 | JY-510 | JY-630 | JY-710 | JY-800 | JY-1000 |
Motor Power(HP) | 5 | 7.5 | 10 | 15 | 20 | 30 | 40 | 60 | 75 |
Crushing Diamesion(x) | 250 | 300 | 380 | 500 | 510 | 630 | 710 | 800 | 1000 |
Crushing Ability(kg/h) | 150-250 | 180-300 | 180-360 | 300-400 | 360-720 | 600-1600 | 800-1600 | 900-1800 | 1010-2000 |
Rotary Cutter(pcs) | 15 | 15 | 18 | 24 | 21 | 21 | 18 | 21 | 15 |
Stationary Cutter(pcs) | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 4 | 4 |
Dimension | 980*650 | 980*750 | 1100*820 | 1220*970 | 1720*1370 | 1720*1500 | 2020*1620 | 2420*1770 | 2520*2020 |
Net Weight(kg) | 350 | 400 | 650 | 900 | 1200 | 1400 | 3000 | 3350 | 4000 |
