Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter

Name: Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter
Brand: Zhangjiagang Friend Machinery Co., Ltd.
SKU: Single screw extruder
Price: 100000.00 USD
Availability: InStock

Brand Name:	Friend
Model Number:	Single screw extruder
MOQ:	one set
Price:	negotiation
Payment Terms:	L/C, T/T
Supply Ability:	50 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu Province,China

Certification:

CE,SGS,TUV

Matieral:

PE Granule

Pipe Layer:

Single Layer Or Multiple Layer

Pipe Diameter:

63-630mm

Material For Machine:

SS304

Control:

PLC Automatic Of Single Screw Rubber Extruder

Contactor:

Siemens

After-sales Service:

Engineers Available To Service Machinery Overseas

Packaging Details:

Film package,also can be wooden package

Supply Ability:

50 set per month

Highlight:

plastic pipe extrusion machine

pvc pipe production line

Product Description

63-630mm plastic PE pipe extruder machine / extrusion line / production line

Characteristic and application:

PE pipe producing line, equipped with different extruding dies and necessary auxiliary machines, can make various PE pipes.

Features of this line:

1. high efficiency single screw extruder: high rotating speed, good compounding effect and stable extrusion ensuring big capacity.

2. extruding die: adopting latest designed die head with spiral distributing flow channel, built-in temperature controlling device which make the extrusion more evenly.

3. vacuum calibrating tank: advanced water loop vacuum calibration, two vacuum chambers ensuring perfect roundness of the pipe, multi-section 6 meter water spraying tank, make sure cooling the pipe thoroughly, the main body of the tank made of stainless steel.

4. haul-off machines: 2 laws, 3 claws, 4 claws, 6 claws and 8 claws are provided to manufacture various pipes, haul-off speed governed by the FUJI or ABB inverter.

5. cutting unit: dust-free cutting, with PLC controlling and meter counter.

6. stacking unit: providing pipe winder or pipe stacker.

7. controlling system: supply manual controlling cabinet and SIEMENS PLC touch screen controlling.

Main technical parameters:

Model	UPVC63	UPVC160	UPVC250	UPVC450	UPVC630
Pipe Diameter mm	Φ16-Φ63	Φ20-Φ160	Φ50-Φ250	Φ160-Φ450	Φ450-Φ630
Vacuum tank length mm	6000	6000	6000	6000	6000
Vacuum degree	-0.03-0.08	-0.03-0.08	-0.03-0.08	-0.03-0.08	-0.03-0.08
Max. haul-off force N/m	10000	15000	20000	30000	40000
Hauling speed m/min	10	6	4	2	0.5-2
Valid haul-off length mm	1000	1500	1500	1600	2400
Cutting mode	Dust-free cutter	Dust-free cutter	Planetary cutter	Planetary cutter	Planetary cutter

Pictures:

PE pipe machine

Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter 0

Vacuum calibration table

Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter 1

200-630mm cutting machine

Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter 2

16-200mm cutting machine

Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter 3

Single layer PE pipe

Single / Multiple Layer PP PE Pipe Extrusion Line 63-630mm Pipe Diameter 4
